Hybrid Audio Technologies LEGATIA L3 kodisi muluus............



sold







The Legatia� L3 is a very unique driver, and satisfies a need in the high-end car audio community for a small diameter, wide-bandwidth midrange driver. You can now put high quality midrange ANYWHERE in your car! The Legatia� L3 has an outstanding extended frequency response; the usable frequency range of this driver exceeds six octaves. With proper filtering, installation techniques, and tuning, this driver will effectively reproduce music tones from as low as 140 Hz to as high as 10,000 Hz at comfortable listening levels. Literally all that is needed to compliment this driver is a set of small diameter soft dome tweeters and a stout midbass driver, for the ultimate three-way front stage system. The L3 has won numerous national- and world-championships in its short tenure on the market, and has already established itself as the best small-diameter midrange on the planet.



Legatia� L3 Thiele-Small Parameters



Overall diameter: 93mm (3.7-inch)

Mounting depth: 46mm

Bolt Circle Diameter: 85mm

Mounting hole: 74mm

Pnom (without crossover) 25W (AES Standard)

Pmax (without crossover): 50W

Pmax (with recommended crossover): 150W

Frequency range: 129Hz - 10,000 Hz

Sensitivity: 85dB (2.83V/1m)

Mms: 2.274g

Cms: 640 um/N

BL: 2.961 T*m

Voice coil diameter: 25.5mm (1-inch)

Impedance: 4 Ohm

DC Resistance: 3.4 Ohm

Fs: 129Hz (free air)

Qms: 3.468

Qes: 0.717

Qts: 0.594

Xmax: 2.6mm (one way)

Vas: 0.63L

Sd: 2733mm2
