JUAL WTS: Power DLS Ultimate A7 (Surabaya)

MusikNyantai

Dijual power DLS Ultimate A Series A7 (5Channel)

4x60W dan 1x300W

kekurangan Tutup power belakang hilang jadi pakai papan

Jual 6,75jt saja

Surabaya

Minat hub 081 2324 9559

Number of channels 5

Amplifier class AB

Mono bridge mode 4 ohm 2 x 200 W RMS

Output power in 2 ohm 4 x 100 W RMS

Output power in 4 ohm 4 x 60 W RMS

Mono sub channel output in 1 ohm 600 W RMS

Mono sub channel 2 ohm 440 W RMS

Mono sub channel 4 ohm 300 W RMS

Frequency range 10 Hz - 50 kHz

Damping factor > 200

S/N ratio, A-weighted > 100 dB

Low level output No

Input impedance, high level N/A

High level input with auto start No

Input sensitivity 0,3 - 7 V

Input impedance > 10 kohm

Filters channel A & B HP: 80 - 400 Hz / 1,6 - 8 kHz (x20)

Filters channel C & D HP: 80 - 400 Hz. LP: 0,3 - 4 kHz / 3 - 40 kHz (x10)

Filter sub channel LP: 50 - 125 Hz

Phase control for subwoofers 0-180 degrees cont. variable

External cooling fan terminal Yes

Remote bass level control Yes

Remote phase shift control Yes

Power consumption (idle) 1,1A

Power consumption (max) 120 A

Rec. power cable Minimum 4AWG / 21 mm2

Fuses 2 x 35 A + 2 x 20 A

Dimension (W x D x H) 605 x 240 x 73 mm (23,82 x 9,45 x 2,87 inches)

Weight 8,1 kg ( 17,86 lb)
