Default Mobo Albatron KX520LE AM2 + VGA PE ZOTAC 8500GT 512 Mb

Kondisi Barang : Baru

Harga :



Lokasi Seller : Jawa Timur


Description :



Ijin Nawarin barang gan, MOBO dan VGA PCI Express



Feature



AMD AthlonTM 64 FX / AthlonTM 64 X2 Dual Core / AthlonTM 64 / SempronTM processors

Socket AM2 with Hyper TransportTM 1000 MHz

4* DDRII 800/ 667/ 533 Memory sockets (Dual Channel).

Realtek 8 Channel HD Audio

Realtek RTL8110SC Gbit LAN

1* PCI Express x16, 1* PCI Express x1, 3* PCI slots

2* SATAII 3 Gb/s channels, SATA RAID 0, 1

1* ATA133 channel

8* USB 2.0/1.1 ports (4 ports by optional cables)



Processor



Socket AM2 with AMD AthlonTM 64 FX / AthlonTM 64 X2 Dual Core / AthlonTM 64 / SempronTM processors



FSB / Transport



1000 MHz



Chipset



Chipset�GNVIDIA nForec 520LE

LAN Chip�GRealtek RTL8110SC Gbit LAN

Audio Chip�GRealtek ALC883

I/O Chip�GFintek F71882FG



Memory



4* DDRII Sockets

DDRII 800/ 667/ 533 NON-ECC DDRII SDRAM up to 8 GB�]Dual Channel�^



Expansion Slots



1* PCI Express x16

1* PCI Express x1

3* PCI slots (PCI 2.3 compliant)



IDE / SATA Connectors



1* ATA133 channel, up to 2* IDE devices

2* SATAII 3 Gb/s channels, up to 2 SATA devices, and support SATA RAID 0, 1



Onboard I/O Connectors



1* Floppy connector

2* USB 2.0/1.1 headers (4 ports by optional cables)

1* CPU fan header (1 fan rotation detection function)

2* System fan headers ( 2 fan rotation detection function )

2 x 5 pin system panel header

1* Parallel port header

1* COM header

1* CD-IN header

1* Front Audio header

1 x 3 pin Power LED header



I/O via Back Panel



PS/2 keyboard/mouse, 4* USB (2.0/1.1), 1* RJ45 LAN port, 1* Line-in/ Line-out/ MIC-in/ Center-LFT/ Surback/ Surround



Power



24-pin ATX power connector, 8-pin ATX 12V power connector



BIOS Feature



4Mb Flash EEPROM

Award BIOS with ACPI, DMI2.0, PnP, WfM2.0, Green Suspend to RAM (S3)

Suspend to Disk (S4) Wake on keyboard/mouse, Wake on LAN/RTC Timer



Hardware Monitoring



3* FAN sensors, CPU/ System voltages and temperature monitoring



Special Feature



Adjustable CPU frequency by 1 MHz increment

Adjustable Vcore, VMemory for overclocking


[/spoiler]
Spoiler for open this:
Spoiler for open this:
for paket mobo:



















Spoiler for open this:
Spoiler for open this:
for Panel belakang:

















Spoiler for open this:
Spoiler for open this:
for Tampak atas:
















Kondisi Mobo masih bagus dan hanya saya pake 1-2 minggu.



Untuk VGAnya udah gak baru lagi, tapi kondisi masih normal banget.

ZOTAC GeForce 8500GT

Memori : 512 Mb

Bit : 128bit

Keterangan ada beberapa kondensator yang telah direplace. Tapi percayalah, kondisi masih normal hasilnya.

Nih penampakannya:


[spoiler=open this] for VGA:
















Saya juga sambahkan satu memori DDR2 1 Gb.

Untuk semua saya tawarkan Rp.550.000,- belum ongkirnya.



Kontak







Terimakasih ke agan-agan semua yang telah menawar, tapi maaf.... SUDAH TERJUAL
